ASME SA1011 Grade 36 is in the Standard Specification for Steel, Sheet and Strip, Hot-Rolled, Carbon, Structural, High-Strength Low-Alloy, High-Strength Low-Alloy with Improved Formability, and Ultra-High Strength . ASME SA1011 Grade 36 general purpose metal ideal for most processing techniques. Applications of ASME SA1011 Grade 36 is Brackets, Gussets, Sheathing, Ornamental projects.
Standard : ASME SA1011
Dimension range : 0.1mm -3mm x 500mm-1550mm x 1000mm-12000mm
ASME SA1011 Grade 36 structural steel plate Mechanical Properties :
|
Mechanical Properties
|
|||||
|
Grade |
Tensile Strength, Ultimate |
Tensile Strength, Yield |
Elongation at Break |
Modulus of Elasticity |
Temperature |
|
Grade 36 TYPE 1 |
>= 365 MPa |
>= 250 MPa |
>= 22 % |
200 GPa |
20.0 °;C |
|
>= 52900 psi |
>= 36300 psi |
>= 22 % |
29000 ksi |
68.0 °;F |
|
|
Grade 36 TYPE 2 |
>= 400 MPa |
>= 250 MPa |
>= 21 % |
200 GPa |
20.0 °;C |
|
>= 58000 psi |
>= 36300 psi |
>= 21 % |
29000 ksi |
68.0 °;F |
|
SA1011 Grade 36 LAHS steel Chemical composition :
|
Chemical composition
|
||||||||||
|
Grade |
C |
Mn |
P |
S |
Cu |
Ni |
Mo |
V |
Cr |
Ti |
|
Grade 36 |
0.25 |
0.90 |
0.035 |
0.04 |
0.20 |
0.20 |
0.05 |
0.008 |
0.15 |
0.008 |
Delivery Status : Rolling, rolling or normalizing probe
ASME SA1011 Grade 36 Low alloy high strength steel application :
Automotive, truck frames, automotive wheels, pipe and tubular, water heaters, agriculture equipment, strappings, stampings, compressor shells, truck frames, railcar components, wheel rims, metal buildings, railroad-hopper cars, doors, shelving, wheel rims, discs,guard rails, pipe and tubular, automotive clutch plates .
Related Product:
SA1011 Gr.30, SA1011 Gr.40, SA1011 Gr.45, SA1011 Gr.50, SA1011 Gr.55
