S355N steel is a kind of normalized or normalized rolled weldable fine grain structural steels. The delivery condition for S355N must be Normalized heat treatment or Normalized rolled way. S355N steel grade material No. Is 1.0490
EN 10025 S355N steel have the good weldable and fine grain structural property. So, it can be used into the steel structural or welded vessel or pressure vessels.
Standard : EN 10025-3
Dimension range : 2-400mm * 1000-3800mm * 3000-18000mm
S355N Low alloy high strength steel Mechanical Properties
|
Mechanical Properties
|
||||||
|
Grade |
Thickness |
Yield Strength |
Tensile Strength |
Elongation |
Charpy V Notch Impact Test |
|
|
Degree |
Min Value |
|||||
|
S355N |
mm |
Min Mpa |
Mpa |
Min % |
-20℃ |
J |
|
5≤t≤16 |
355 |
470-630 |
21% |
40 |
||
|
63＜t≤100 |
315 |
470-630 |
40 |
|||
|
100＜t≤250 |
275 |
450-600 |
40 |
|||
|
Note: Impact energy for impact test is on longitudinal |
||||||
S355N structural steel Chemical Composition
|
Chemical Composition
|
|||||||
|
Grade |
The Element Max (%) |
||||||
|
C |
Si |
Mn |
P |
S |
N |
Al |
|
|
S355N |
0.22 |
0.55 |
0.85-1.75 |
0.035 |
0.030 |
0.017 |
0.015 |
|
Cr |
Cu |
Mo |
Nb |
Ni |
Ti |
V |
|
|
0.35 |
0.60 |
0.13 |
0.06 |
0.55 |
0.06 |
0.14 |
|
Carbon Equivalent: CEV= 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%
|
Thickness, mm
|
Max CEV based on the ladle analysis |
|
5≤t≤63 |
0.43% |
|
63＜t≤100 |
0.45% |
|
100＜t≤250 |
0.45% |
Delivery Status : Normalizing rolling
S355N Normalized steel plate/sheet application :
S355N low alloy plate for the manufacture of various types of construction machinery, such as mining and construction of various types of drilling rigs, shovels, electric wheel dumpers, mining vehicles, excavators, loaders, bulldozers, all kinds of cranes, coal mine hydraulic support And other mechanical equipment and other structural parts.
