S275M steel is a kind of TMCP( Thermo Mechanical Control Process) rolled weldable fine grain structural steels. The delivery condition for S275M must be TMCP rolled way with Low temperature impact test. M means -20 min degree impact test. ML means -50 min degree impact test.
EN 10025 S275M steel have the good weldable and fine grain structural property. So, it can be used into the steel structural or welded vessel or pressure vessels. At the same time, S275M also can be used in the offshore or any other applications which request the high tensile strength.
Standard : EN 10025-4
Dimension range : 2-150mm * 1000-3800mm * 3000-18000mm
S275M structural steel plate Mechanical Properties
|
Mechanical Properties
|
||||||
|
Grade |
Thickness |
Yield Strength |
Tensile Strength |
Elongation |
Charpy V Notch Impact Test |
|
|
Degree |
Min Value |
|||||
|
S275M |
mm |
Min Mpa |
Mpa |
Min % |
-20℃ |
J |
|
5≤t≤16 |
275 |
370-530 |
24% |
40 |
||
|
63＜t≤100 |
245 |
350-510 |
40 |
|||
|
100＜t≤120 |
240 |
350-510 |
40 |
|||
|
Note: Impact energy for impact test is on longitudinal |
||||||
S275M TMCP steel plate/sheet Chemical Composition
|
Chemical Composition
|
|||||||
|
Grade |
The Element Max (%) |
||||||
|
C |
Si |
Mn |
P |
S |
N |
Al |
|
|
S275M |
0.15 |
0.55 |
1.60 |
0.035 |
0.030 |
0.017 |
0.015 |
|
Cr |
Cu |
Mo |
Nb |
Ni |
Ti |
V |
|
|
0.35 |
0.60 |
0.13 |
0.06 |
0.35 |
0.06 |
0.10 |
|
Carbon Equivalent: CEV= 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%
|
Thickness, mm
|
Max CEV based on the ladle analysis |
|
5≤t≤40 |
0.34% |
|
40＜t≤63 |
0.35% |
|
63＜t≤150 |
0.38% |
Delivery Status : Hot rolling, controlled rolling, normalizing and so on
S275M Low alloy high strength steel application :
S275M steel plate/sheet is mainly used in the manufacture of bridges, ships, vehicles, boilers, high pressure vessels, oil and gas pipelines, large steel structures.
