ASTM A203 Grade E is a kind of Ni-alloy steel material used to fabric high temperature pressure vessels. ASTM A203 Grade E this property is based on it's Ni composition.A203 Grade E is used in fabricators serving industry, especially in the oil, gas and chemical supply markets. ASTM A203 has five grades or levels-- Grade A/B/D/E/F.
Standard: ASTM A-203/A-203M
Dimension range : 1.5mm -260mm * 1000mm-4000mm * 1000mm-18000mm
A203 Grade E steel plate Mechanical Properties
|
Mechanical Properties
|
||||||
|
Grade |
Thickness |
Yield Strength |
Tensile Strength |
Elongation |
Charpy V Notch Impact Test |
|
|
Degree |
Min Value |
|||||
|
A203Gr.E |
mm |
Min Mpa |
Mpa |
Min % |
- |
J |
|
5≤t≤50 |
275 |
485-620 |
21% |
- |
||
|
50≤t≤200 |
275 |
485-620 |
17% |
|
|
|
|
Note: Impact energy for impact test is on longitudinal |
||||||
A203 Grade E Boiler steel plate Chemical Composition
|
Chemical Composition
|
|||||||
|
Grade |
The Element Max (%) |
||||||
|
C |
Si |
Mn |
P |
S |
Ni |
N |
|
|
A203Gr.E |
0.20-0.23 |
0.13-0.45 |
0.78-0.88 |
0.035 |
0.035 |
2.03-2.57 |
|
Delivery Status : Normalizing + tempering or tempering state
A203 Grade E pressure vessel steel application :
A203 Grade E steel is widely used in petroleum, chemical, power station, boiler and other industries, for the manufacture of reactor, heat exchanger, separator, spherical tank, paint tank, Oil gas cylinders, high-pressure water pipe hydropower stations, water turbines and other equipment and components.
