20MnB5 structural alloy steel
20MnB5 steel plate

20MnB5 structural alloy steel is used for mechanical parts and all kinds of engineering components and contains one or several kinds of a certain amount of alloy element in steel.

20MnB5 Alloy structural steel is widely used in ships,vehicles,aircraft,missiles,weapons,railways,Bridges,pressure vessels and so on. 20MnB5 structural alloy steel is provided with higher yield strength,tensile strength, endurance strength,yield ratio (about 0.85 generally ) enough plasticity and toughness.

20MnB5 steel plate chemical composition %

C

Si
max

Mn

P max

S max

Nmax

B

0.17-0.23

0.40

1.10-1.40

0.025

0.035

0.009

0.0008-0.0050

20MnB5 alloy steel plate Mechanical properties a at room temperature in the quenched and tempered condition

Grade

Mechanical properties for the ruling section
with a diameter (d) or for flat products thickness (t) of



20MnB5



d ≤ 16 mm t ≤ 8 mm

16 mm < d ≤ 40 mm 8 mm < t ≤ 20 mm

Remin(Mpa)

Rm(Mpa)

A min(%)

Zmin(%)

KVbmin(J)

Remin(Mpa)

Rm(Mpa)

Amin(%)

Zmin(%)

KVbmin(J)

700

900-1050

14

55

~

600

750-900

15

55

60

Technical specifications,French standards Quenched and tempered steel 20MnB5 datasheet,20MnB5 Chemical compositions, mechanical properties from Steelmaking, ESR melted, Blooming,NF 20MnB5 Forging,Hot rolling,Heat treatment, Straightening,Ultrasonic test,Cold working or Machined.Technical specification - NF EN 10083-3.We also possess the advanced precision machining equipments for further processing of 20MnB5 Alloy structural steel.Please just let us know what you inquire.so contact us.
